AXIS Q1786-LE Network Camera LED Illumination Outdoor Ready 01162-001
Robust, first-class 4 MP video with 32x optical zoom 4 MP / Quad HD 1440p at up to 60 fps OptimizedIR with up to 80 m (262 ft) range -40 °C to 60 °C operating temperature Electronic image stabilization AXIS Guard Suite included AXIS Q1786-LE Network Camera is a tough, top-of-the-line camera with outstanding 32x optical zoom. It’s an all-integrated camera that’s all set to take on just about any challenge, indoors or out. How far would you go? Go ahead and place AXISQ1786-LE almost anywhere to capture your targeted surveillance area. You’ll be able to count on superior, high-resolution footage – still or motion-packed – in bright light, backlight or absolutely no light at all.That’s because AXIS Q1786-LE features 32x optical zoom,Axis OptimizedIRat up to 80 m and high resolution video in 4 MP or Quad HD 1440p at up to 60 fps. It’s gotAxis Forensic WDRfor clarity even when there are both dark and light areas in the scene andAxis Lightfinderfor high-quality – color – images even recorded in near darkness. AndAxis Zipstreampreserves the forensic detail you need, while lowering bandwidth and storage requirements by 50% or more. Mother Nature watch out Engineered to be just as effective outdoors as it is indoors, AXIS Q1786-LE can withstand temperatures between -40 °C to 60 °C (-40 °F to 140 °F). It haselectronic image stabilizationand IK10-rated casingfor impact resistance. It’s IP66-, IP67-, and NEMA 4X -rated for protection against ice, water, corrosion and dust. And its defog functionality ensures clear images despite fog or smog. In other words, AXIS Q1786-LE can take whatever nature – or human beings – throw at it. And still come out on top. But that’s not all… Want more? AXIS Q1786-LE keeps right on delivering. It comes with AXIS Motion Guard,AXIS Fence Guardand AXIS Loitering Guardpre-installed for proactive surveillance. It has extra capacity for other advanced analytics as well. It supports video with sound and features scene profiles , shock detection, corridor format with auto-rotation and barrel distortion correction for always-great image quality and cost-effective installation. You can even add additional functionality thanks to I/O ports. Reliable identification with 32x optical zoom Image sensor CMOS Image sensor size 1/1.8 Lightfinder Lightfinder Wide dynamic range Forensic WDR Min illumination/ light sensitivity (Color) 0.18 lux Min illumination/ light sensitivity (B/W) 0 lux Max video resolution 2560x1440 Max frames per second 50/60 Electronic image stabilization Yes Focal length 4.3 - 137 mm Optical zoom 32 Horizontal field of view 60 - 2.3 ° Vertical field of view 39-1.3 ° Zipstream Yes H.264 Baseline, High, Main Motion JPEG Yes Audio Support Yes PoE Class 3 Signed firmware Yes Remote zoom Yes Built-in IR Yes Local storage (memory card slot) Yes Operating temperature -40 to 60 °C Outdoor Ready Yes Vandal rating IK10 IP rating IP66, IP67 Designed for repaint Yes Sustainability PVC free Power (max) 13.8 W Power (average) 8.6 W
