AXIS Q7900 Video Encoder Rack 0287-009

they are 1-, 4- or 6-channel blades can be used. Blade No. of channels Video compression* Frames per second in max. resolution External inputs/outputs PTZ support Audio AXIS P7224 4 H.264 Multiple streams at 30/25 in D1 per channel 4 configurable Motion JPEG AXIS Q7406 6 H.264 Multiple streams at 30/25 in D1 per channel 12 configurable Motion JPEG AXIS Q7414 4 H.264 Multiple streams at 30/25 in D1 per channel 8 configurable Motion JPEG AXIS 243Q 4 MPEG-4 30/25 in 4CIF per channel 4/4 Motion JPEG AXIS 241Q 4 MPEG-4 21/17 in 4CIF using 1 channel, 20/17 in CIF per channel using 4 channels 4/4 Motion JPEG 30/25 in 4CIF using 1 channel, 30/25 in CIF per channel using 4 channels * H.264 is also known as MPEG-4 Part 10/AVC. In the table, MPEG-4 refers to MPEG-4 Part 2. Frame rate = NTSC/PAL
