AXIS Camera Station S1224 Rack Recording Server 03237-001

Brand: AXIS
Model: AXIS-S1224-RACK

quality, reliability, and support. Part of an Axis end-to-end solution, all supported products are available in one price list for a one-stop-shop experience. Furthermore, with an intuitive installation wizard and AXIS Recorder Toolbox, AXIS S1224 help ensure every installation is trouble-free. note For further information please visit Axis on-site support guidelines . Part number for ordering Name Axis region Part number AXIS S1224 Rack 12 TB AR, AU, BR, CN, EU, IN, JP, KR, UK, US 03237-001 Form factor Rack 1U Included licenses 24 System storage (TB) 12 TB Total HDD bays 2 Free HDD bays 1 HDDs included 1 Supported RAID level 0, 1, 10 Default RAID level Not configured Validated video channels 32 Validated recording bitrate (Mbit/s) 256 Operating system Windows 11 IoT Enterprise LTSC

Product Features


Out-of-the-box ready recording servers with 24 AXIS Camera Station Pro Licenses included

  • Scalable and powerful solution

  • One empty hard drive bay for storage expansion

  • Optimized energy consumption

  • 24 AXIS Camera Station licenses included

  • Extensive support and 5-year warranty


This out-of-the-box, ready-to-use recording server features powerful components for top-class performance. And it’s easy to scale and expand your system as your needs grow.



Top class performance and reliability

Featuring powerful components, in a 1U rack form factor this recording server offers support for powerful applications and features. This secure device complies with government policies and uses a Trusted Platform Module (TPM) that is FIPS 140-2 level 2, which increases the security of the product and ensures recorded video is stored encrypted on the hard drive. It comes with a built-in operating system recovery stored on the device, to make it easier to recover data if needed.


Flexible, scalable solution

AXIS S1224 Rack is ideal for demanding applications. With great scalability, it’s easy to expand your system as it grows without the need for additional hardware. It includes 24 AXIS Camera Station Pro licenses. And you can expand your system up to a recording bitrate of 300 Mbit/s (approximately 32 video channels). AXIS S1224 Rack is available with 12 TB storage and can easily be expanded with one additional hard drive, based on your specific requirements. Hard drives are available as optional accessory.


Quality and ease-of-use

This reliable recording server and client comes pre-loaded with AXIS Camera Station Pro licenses and all necessary software, so there’s no need to spend time selecting, configuring, and testing hardware. Plus, with services such as Keep Your Hard Drive and Next Business Day Onsite Support*, as well as a 5-year warranty, you can depend on Axis for first-class quality, reliability, and support. Part of an Axis end-to-end solution, all supported products are available in one price list for a one-stop-shop experience. Furthermore, with an intuitive installation wizard and AXIS Recorder Toolbox, AXIS S1224 help ensure every installation is trouble-free.

note

For further information please visit Axis on-site support guidelines.


Part number for ordering

NameAxis regionPart number
AXIS S1224 Rack 12 TB AR, AU, BR, CN, EU, IN, JP, KR, UK, US 03237-001

Technical Specifications

Property DescriptionProperty Value
Property descriptionProperty value
Form factorRack 1U
Included licenses24
System storage (TB)12 TB
Total HDD bays2
Free HDD bays1
HDDs included1
Supported RAID level0, 1, 10
Default RAID levelNot configured
PoE total output power
Power over Ethernet Plus
Validated video channels32
Validated recording bitrate (Mbit/s)256
Operating systemWindows 11 IoT Enterprise LTSC
