Bosch FCS-8000-VFD-B AVIOTEC IP starlight 8000 Video-based fire detection F.01U.317.536
level with IR illumination (lx) 0 Standard G.711, 8 kHz sampling rate L16, 16 kHz sampling rate AAC-LC, 48 kbps at 16 kHz sampling rate AAC-LC, 80 kbps at 16 kHz sampling rate Signal-to-Noise Ratio >50 dB Audio Streaming Full-duplex / half duplex Operating Temperature -20°C to +50°C (-4°F to 122°F) Storage Temperature -30°C to +70°C (-22°F to +158°F) Operating Humidity 20% to 93% RH Storage Humidity up to 98% RH Analog video out SMB connector, CVBS (PAL/NTSC), 1 Vpp, 75 Ohm Audio line in 1 Vrms max, 18 kOhm typical, Audio line out 0.85 Vrms at 1.5 kOhm typical, Audio connectors 3.5 mm mono jack Alarm input 2 inputs Alarm input activation +5 VDC nominal; +40 VDC max. (DC-coupled with 50 kOhm pull-up resistor to +3.3 VDC) (< 0.5 V is low; > 1.4 V is high) Alarm output 1 output
