Bosch LA1-UW36-L1 Column 36W White F.01U.283.989

13.5 kHz opening angle 1 kHz/4 kHz (-6 dB) 1 kHz/4 kHz (-6 dB) Horizontal 190°/88°190°/88' Vertical 30°/8°30°/8' Rated input voltage 100 V and 70 V 100 V and 70 V Rated impedance 417 ohms 278 ohms Connector 5 pole push-in terminal block 5-pole push-in terminal block *Technical performance data according to iec 60268-5 Mechanical Dimensions: (height x width x depth) 841 x 151 x 129mm (33.1 x 5.9 x 5.1 inches) weight LA1-UW24-X1 weight LA1-UW36-X1 5.5 kg (12.1 lbs) 6 kg (13.2 lb) Black (D1) or White (L1) Cabinet/fabric (D1) matches RAL 9004/RAL 9004 Cabinet/fabric (L1) matches RAL 9010/RAL 7044 Environmental Working temperature -25 degrees Celsius to +55 degrees Celsius (-13°F to +131°F) Storage temperature -40 degrees Celsius to +70 degrees Celsius (-40°F to +158°F) relative humidity <95%
