Bosch LB1-BW12-L Bi-directional Cabinet Speaker White F.01U.522.178
of international installation and safety regulations F.01U.522.178 712 LB1-BW12-L 12W two-way speaker, white Maximum power 18W Rated power 12 / 6 / 3 W Sound pressure level (1 kHz, 1 meter) 97 / 86 dB (SPL) at 12 W/1 W Effective frequency range (-10 dB) 140 Hz to 20 kHz opening angle 270° / 165° at 1 kHz/4 kHz (-6 dB) Rated input voltage 100 V Rated impedance 833 ohms Interface 4-pin push-in junction box Dimensions (H x W x D) 240 x 238 x 133 mm (9.4 x 9.3 x 5.24 inches) Weight 1.5 kg (3.3 lbs) Color black (D) or white (L) Speaker/fabric (D) complies with RAL 9004 standard Speaker/fabric (L) complies with RAL 9010/RAL 7044 standard operating temperature -25 ºC to +55 ºC (-13 ºF to +131 ºF) Storage and Shipping Temperature -40 ºC to +70 ºC (-40 ºF to +158 ºF) relative humidity <95%
