Bosch LTC 0485/21 1/3-inch 540TVL Nightsense DinionXF WDR Color Box Camera F.01U.004.182
Indoor Automatic White Balance ATW (2500–10000 K), AWB hold, manual WB selectable Auto Gain Control Auto (maximum level selectable to 28 dB) or Image Pixels Total 768 x 492 Image Device 1/3-inch CCD Electronic Shutter Auto (1/60 (1/50) to 1/500000), fixed, flickerless, Default Dimensions (W x H) 59 x 67 x 122 mm Infrared Distance Non Infrared Resolution < 1MP Sensor Option 1/3" CCD S/N Ratio >50 dB Power Consumption 4W Operating Temperature -20 °C to +50 °C(-4 °F to +122 °F) Operating Humidity 20% to 93% Relative humidity Minimum Scene Illumination 0.24 lux / 0.10 lux (NightSense) (0.024 fc / 0.01 fc (NightSense)) Mount Type Bracket Required On Screen Display Menu Yes Wide Dynamic Range Yes Motion Detection Tracking Yes Back Light Compensation Yes Digital Noise Reduction Yes
