Bosch NDN-832V02-IP 1/2.7 inch CMOS day and night HD camera 1080P 1.8-3mm IP66 IVA activated F.01U.170.535
(12 VDC)13.4 W | 15.8 W IVA (24 VAC)12.2 W | 13.4 W IVA (PoE 48 VDC) Operating Temperature 50°C to +60°C (-58°F to 140°F) Operating Humidity 20% to 93% RH Minimum Scene Illumination Color 0.50 lx(0.05 fc)Monochrome tbd lx(tbd fc) Lens Size 1.8-3mm Camera Signal Network IP Lens Type Varifocal Video Output RJ-45 Back Light Compensation On/off Automatic White Balance ATW (2500 to 10000K), ATWhold and manual Infrared Distance Non Infrared Compression Method H.264, JPEG Connection Type Wired Image Pixels Total 1920 x 1080 Image Device 1/2.7" CMOS Electronic Shutter Auto (1/50 [1/60 Dimensions (W x H) 208 x 151 mm Durability Vandal Resistant, Weather Resistant Motion Detection Tracking Yes Privacy Masking Yes Wide Dynamic Range Yes Auto Gain Control Yes Day/Night Yes Digital Noise Reduction Yes
