Samsung Hanwha HRX-1632 16-Channel Pentabrid Digital Video Recorder

Brand: Hanwha

Model: HRX-1632

Camera(NTSC/PAL)\n(Main Stream)4M(4M Half 1280*1440) 15/12fps, 2M 15/12fps, 720p 30/25fps, 960H 30/25fps (NTSC/PAL per CH)\n(Sub Stream) 720p or higher : 640x368 full fps/CH, SD signal : upto CIF 15/12 fps/CH\n* The maximum recording frame rate depends on the frame rate of the input camera. Transmission Bandwidth Max. 100Mbps Input/Output 16 Lline in (Built in 4 Line, Option : Audio Extension Cable) / 1Line line out Audio Communication 2-Way Max Remote Users Search(3), Live Unicast(10), Multicast(20) Security IP address filtering, User access log, 802.1x Authentication, Encryption (ID/PW, Recording, Transmission, Backup)\nDevice Certificate(Hanwha Techwin Root CA) Viewer Software SSM, Webviewer, SmartViewer, Wisenet Mobile Viewer\nSupport SDK/CGI(SUNAPI) for integration to 3'rd party VMS
