Honeywell HVCD-2200IV 1080P Infrared Dome Network Camera
HVCD-2200IV 1080P infrared dome network camera Honeywell HVCD-2200IV infrared dome network camera combines world-class imaging devices and camera technology with innovative IP network technology, providing users with 1080P ultra-high-quality images. HVCD-2200IV HD Infrared Dome Network Camera is the best solution in the field of cost-effective video surveillance with its high-quality image effect. Honeywell HVCD-2200IV supports 1080P high-definition video, H.265+/H.265 high-efficiency encoding and compression, PoE Ethernet power supply and ONVIF interface protocol, and can still present ultra-high-quality high-definition images even in a limited bandwidth environment . Honeywell HVCD-2200IV has a built-in 2.8-12mm manual zoom lens, allowing users to adjust the focal length of the camera lens to the best viewing angle according to the on-site monitoring environment. HVCD-2200IV has a built-in infrared light, the maximum infrared distance can reach 50 meters, and it has a real day and night switching mode, providing users with clear black and white images in low-light or total darkness environments. Honeywell HVCD-2200IV supports PoE Ethernet (IEEE802.3af), and can directly supply power to IP cameras through network cables, helping users save the use of power adapters and effectively reducing installation costs. In order to increase the installation flexibility of HVCD-2200IV, this network camera also supports DC12V power supply. Honeywell HVCD-2200IV has elegant appearance design and convenient installation, making it an ideal choice for various security and monitoring applications. Its protection level is IP67 and anti-riot level IK10, and it is widely used in various indoor or outdoor places, such as commercial Buildings, shopping malls, hotels, education and health, banking and finance, residential quarters, etc. 1/2.8” progressive scan CMOS Support 1920x1080@25fps Support H.265+/ H.265/ H.264 encoding Real day and night conversion Digital WDR Infrared distance 50m meters Zoom lens 2.8 - 12mm manually adjustable 3D digital noise reduction, BLC, motion detection, video occlusion Support up to 128GB front-end storage Protection grade IP67, anti-riot grade IK10 Support ONVIF protocol Support PoE/DC12V power supply Product model HVCD-2200IV Image Sensor 1/2.8" progressive scan CMOS Minimum illumination color: 0.01Lux; black and white: 0Lux (infrared light on) Electronic Shutter 1/3 ~ 1/100,000 s Day and night mode True day and night conversion TDN (ICR infrared filter) SNR 52dB WDR DWDR (number) focal length 2.8 ~ 12mm, manually adjustable angle of view Horizontal 98° ~ 34° , Vertical 51° ~ 19° (wide-tele) aperture F1.6 IR distance 50m Audio and video encoding video encoding H.265+/ H.265/ H.264 main stream: x x encoding characteristics 1920 1080@25fps/50Hz; 1920 1080@30fps/60Hz sub stream: 640 x 480@25fps/50Hz; 640 x 480@30fps/60Hz H.265 encoding Main Profile H.264 encoding High Profile/ Main Profile/ Baseline Profile Video bit rate 32Kbps ~ 8Mbps Audio and video function image enhancement BLC (Back Light Compensation), 3D DNR (3D Digital Noise Reduction) Image Settings AGC, Brightness, Contrast, Saturation, Sharpness, White Balance, Anti-Flicker, Mirroring, Privacy Masking, Watermark Protection ROI Support a region ROI (Region of Interest) Insight Support motion detection, video occlusion alarm Internet function Network protocol HTTPS, HTTP, TCP/IP, UDP, FTP, ICMP, IGMP, RTP, RTSP, RTCP, DHCP, DNS,DDNS, PPPoE, NTP, UPnP, SMTP, SNMP, 802.1x, Bonjour, IPv4/v6, QoS Interface Protocol ONVIF(Profile S, G) browser IE8 and above Number of simultaneous preview videos 6 safe mode Authorized username and password, HTTPS encryption, IEEE 802.1X authentication, IP address filtering event triggered Motion detection, masking alarm, network disconnection, IP address conflict, illegal login Interfaces Network Interface 1x RJ45, 10M/100M network adaptive video output Analog Video Output (1Vp-p, BNC) front-end storage Built-in MicroSD/SDHC/SDXC slot, support up to 128GB conventional Operating temperature -30° C ~ 50° C Working humidity ≤95% (no condensation) protection level IP67, anti-riot level IK10 power supply DC12V/ PoE(802.3af, Class 3) power consumption Maximum 6W/ 8W material Metal and plastic size Φ 141 x 100 mm weight 0.80kg * Note: Product design and product specifications are subject to upgrades and changes without prior notice Ordering Information HVCD-2200IV 1080P infrared dome network camera, 1/2.8"CMOS, H.265+/H.265/H.264, TDN, DWDR, 3DDNR, zoom lens (2.8-12mm), infrared distance 50m, support motion detection, Support MicroSD card storage, ONVIF, IP67, IK10, DC12V/PoE HBT-Security-HVCD-2200IV-May.2019-CN/V2
