Huawei IPC6285-VWZ-LPR 4K HD Starlight Micro Mount Network Integrated Camera

interface, support clear channel Alarm interface 2 alarm inputs, 2 alarm outputs Audio interface 1 audio input, 1 audio output Storage interface 1 Micro SD card slot, support SDHC / SDXC, maximum capacity 128GB Analog video 1 CVBS composite analog video signal (BNC interface) Power supply AC24V ±25%, PoE ++ power supply Power consumption 53.6 W maximum power consumption; 21 W typical power consumption Operating temperature -40°C~60°C Operating humidity 5% ~ 95% (non-condensing) Lightening protectionlevel 10kV surge Ingress Protection Rating IP66 Riot rating IK10 (except windows) Railway standards Compliant with rail-side electromagnetic compatibility EN50121-4 Weight Net weight 6.6kg, gross weight 8.6 kg Dimensions Equipment 516.0 x 215.6 x 159.0mm Packaging 678.0 x 329.0 x 325.00 mm
