Huawei IPC6525-Z30-S 2MP 30x Infrared Zoom Smart High Speed Dome Camera
1 alarm output Storage interface 1 Micro SD card slot, support SDHC / SDXC card, maximum capacity 64GB power supply PoE (IEEE 802.3at, does not support heating) AC24V ±25%, DC24V ±20% (DC power supply is non-polar) supports DC / AC adapter power supply and PoE hot backup power Maximum power consumption 40.8 W; typical power consumption 13.3 W (with heater on) Operating temperature -40°C ~ 60°C, -20°C ~ 60°C (PoE power supply) Operating humidity 5% ~ 95% (non-condensing) Lightening protectionlevel 6kV surge Ingress Protection Rating IP66 Riot rating IK10 Railway industry certification Meets EN 50121-4 electromagnetic compatibility standards and EN50125-3 vibration standards Weight Net weight 4kg, gross weight 5.7kg Dimensions Equipment Φ220.0mm x 320.1mm Packaging 295.0 x 295.0 x 510.0mm
