TP-LINK TL-POE260S dual-port standard PoE power supply 2 100M ports 2 100M PoE ports 33W
for webcams, APs such as network cameras, APs such as standard PoE, or with standard PoE separator (TL-POE160R, TL-POE10R, etc.), providing a stable power supply and data transmission for non-POE devices. Supported standards IEEE 802.3,IEEE802.3i,IEEE 802.3u,IEEE 802.3af,IEEE 802.3at port POE port: 2 10/100M RJ45 ports LAN port: 2 10/100M RJ45 ports Network media 10Base-T: Category 5 or above UTP/STP (≤100m) 100Base-T: Category 5 or above UTP/STP (≤100m) Input parameters 220V~ 50Hz 0.3A Output parameters 48VDC 0.7A +4,5pins;-7,8pins Indicator light PWR (power indicator) Use environment Operating temperature: 0°C~40°C (32°F~104°F) Storage temperature: -40°C~70°C (-40°F~158°F) Operating humidity: 10%~90%RH Non-condensing Storage humidity: 5%~90 %RH does not condense size 110mmx57mmx33.5mm
Product Features
Double Standard PoE Power Appliance TL-POE260S is fully compliant with the IEEE 802.3af/at standard, providing 2 PoE output ports, which can be transmitted to the network cable. The maximum output power of the single port is 30W, the maximum power of the double port is 33.6W, and the maximum transmission distance is 100m. TL-POE260S adopts built-in power supply, no configuration, plug and play. It can be used for webcams, APs such as network cameras, APs such as standard PoE, or with standard PoE separator (TL-POE160R, TL-POE10R, etc.), providing a stable power supply and data transmission for non-POE devices. |
Technical Specifications
| Property Description | Property Value |
|---|---|
| Supported standards | IEEE 802.3,IEEE802.3i,IEEE 802.3u,IEEE 802.3af,IEEE 802.3at |
| port | POE port: 2 10/100M RJ45 ports LAN port: 2 10/100M RJ45 ports |
| Network media | 10Base-T: Category 5 or above UTP/STP (≤100m) 100Base-T: Category 5 or above UTP/STP (≤100m) |
| Input parameters | 220V~ 50Hz 0.3A |
| Output parameters | 48VDC 0.7A +4,5pins;-7,8pins |
| Indicator light | PWR (power indicator) |
| Use environment | Operating temperature: 0°C~40°C (32°F~104°F) Storage temperature: -40°C~70°C (-40°F~158°F) Operating humidity: 10%~90%RH Non-condensing Storage humidity: 5%~90 %RH does not condense |
| size | 110mmx57mmx33.5mm |
