TP-LINK TL-SG2216 industrial grade switch 14GE 2SFP iron shell layer 2 supports port isolation VLAN QoS
rate/duplex Layer 2 switching Support port address dynamic learning Support port aggregation Port mirroring Support traffic statistics Support local entry/exit monitoring Support cable detection and loopback detection Multicast Support IGMP V1/V2/V3 Support multicast address display Support maximum 128 multicast entries VLAN Support 802.11Q VLAN, MTU VLAN, port VLAN Quality of Service (QoS) Support 4 port queues Support port priority, 802.1P priority, DSCP priority Support port speed limit, storm suppression System Management Support management via Web page Support PC software management System Tools Support software upgrade Support configuration backup and configuration recovery Support system restart and software reset Packaging accessories Wall-mounted parts Warranty card User manual
Product Features
|
Technical Specifications
| Property Description | Property Value |
|---|---|
| Protocol standard | IEEE 802.3,802.3i,802.3u,802.3x,802.3ab,802.3z |
| Port shape | 14 Gigabit RJ45 ports 2 Gigabit SFP ports |
| Indicator light | 16 status indicators Link/ACT PWR1, PWR2, PWR3 |
| power input | DC input voltage 12/24/48 VDC (9.6~ 60 VDC) input current 0.36A (MAX) support reverse connection protection |
| Switch performance | Support store and forward MAC address table depth 2K |
| DIP | Support broadcast storm protection, support WEB management, support port interruption alarm |
| structure | IP30 protection grade Product size 137mm*128mm*65.4mm rail/wall mounting |
| temperature | Working temperature -40°C — 75°C Storage temperature ‒40°C — 85°C |
| humidity | Operating humidity 10%RH — 90%RH, non-condensing Storage humidity 5%RH — 90%RH, non-condensing |
| Certification Standards_EMS | IEC/EN 61000-4-2,Level 4 IEC/EN 61000-4-3,Level 4 IEC/EN 61000-4-4,Level 4 IEC/EN 61000-4-5,Level 3 IEC/EN 61000-4-6,Level 3 IEC/EN 61000-4-8,Level 5 IEC/EN 61000-4-9,Level 5 IEC/EN 61000-4-10,Level 5 |
| Port configuration | Support port open/close Support port flow control open/close Support port rate/duplex |
| Layer 2 switching | Support port address dynamic learning Support port aggregation |
| Port mirroring | Support traffic statistics Support local entry/exit monitoring Support cable detection and loopback detection |
| Multicast | Support IGMP V1/V2/V3 Support multicast address display Support maximum 128 multicast entries |
| VLAN | Support 802.11Q VLAN, MTU VLAN, port VLAN |
| Quality of Service (QoS) | Support 4 port queues Support port priority, 802.1P priority, DSCP priority Support port speed limit, storm suppression |
| System Management | Support management via Web page Support PC software management |
| System Tools | Support software upgrade Support configuration backup and configuration recovery Support system restart and software reset |
| Packaging accessories | Wall-mounted parts Warranty card User manual |
