AXIS 30 W Midspan 02172-009 02172-004 02172-002

Brand: AXIS
Model: AXIS-30-W-MIDSPAN
Weight: 145g
Dimensions: 30mm x 46mm x 140.10mm

For indoor use, 240 V AC IEEE 802.3af and IEEE 802.3at 10/100/1000 Mbps 100 to 240 V AC Plug-and-play AXIS 30 W Midspan is a 1-port midspan that can deliver up to 30 W to one network device. It is IEEE 802.3af (15 W) and IEEE 802.3at (30 W) compliant, which ensures compatibility with most Axis network products with built-in PoE. Power over Ethernet (PoE) offers an easy, fast and cost-effective solution for powering network products. With a single network cable, a PoE midspan injects power to the network device with built-in PoE support and enables data communication between the device and the switch. No need to replace existing Ethernet switches and cabling infrastructure. System example Part number for ordering Name Axis region Part number AXIS 30 W Midspan US 02172-004 AXIS 30 W Midspan UK 02172-003 AXIS 30 W Midspan EU 02172-002 AXIS 30 W Midspan IN 02172-113 AXIS 30 W Midspan BR 02172-012 AXIS 30 W Midspan AU 02172-006 AXIS 30 W Midspan JP 02172-005 AXIS 30 W Midspan AR 02172-008 AXIS 30 W Midspan KR 02172-007 AXIS 30 W Midspan CN 02172-009
