AXIS F2137-RE Fisheye Sensor 02869-001

vehicles and industrial machines. It features SMA connectors to ensure a tight connection between the sensor and the cable. Plus, the cable itself features a SMA-FAKRA connector to further ensure ruggedized installation. Part number for ordering Name Axis region Part number AXIS F2137-RE Fisheye Sensor AR, AU, BR, CN, EU, IN, JP, KR, UK, US 02869-001 AXIS F2137-RE Fisheye Sensor, 8 pcs AR, AU, BR, CN, EU, IN, JP, KR, UK, US 02869-021 Image sensor CMOS Wide dynamic range WDR Min illumination/ light sensitivity (Color) 0.25 lux Max video resolution 2592x1944 Max frames per second 50/60 Focal length 1.98 mm Varifocal lens No Aperture 2 Horizontal field of view 185 ° Vertical field of view 125 ° Lens mount M12 Operating temperature -40 to 60 °C Outdoor Ready Yes IP rating IP66, IP67, IP6K9K
