AXIS Q6358-LE PTZ Camera 02977-301 02977-009 02977-004
1/1.8" Wide dynamic range Forensic WDR Signed OS Yes Secure boot Yes Built-in IR Yes OptimizedIR Yes Local storage (memory card slot) Yes Operating temperature -50 to 55 °C Outdoor Ready Yes Vandal rating IK10 IP rating IP66,IP67 Designed for repaint Yes Autotracking version Autotracking 2 Orientation aid orientation aid PTZ Max video resolution 3840x2160 Max frames per second 50/60 Day and Night functionality Yes Electronic image stabilization Yes Focal length 6.91 - 214.64 mm Horizontal field of view 58.5 - 2.3 ° Vertical field of view 34.9 - 1.4 ° Optical zoom 31 Pan range 360 endless Tilt range +20 to -90 Guard tour preset position tour Digital zoom 12 Zipstream Yes H.264 Baseline, High, Main H.265 Yes AV1 On Motion JPEG Yes Audio Support * Yes / - Active tampering Yes PoE Class 6
Product Features
4K UHD, AI-powered PTZ for extreme low light
1/2" sensor with 31x optical zoom
Forensic WDR, Lightfinder, and OptimizedIR
Next-generation AI-powered analytics
Axis Zipstream with AV1, H.264, H.265
Built-in cybersecurity with Axis Edge Vault
Built on ARTPEC-9, this high-performance, AI-powered PTZ camera delivers unmatched image quality with great detail and high performance in all light conditions. Axis Edge Vault provides a hardware-based cybersecurity platform that safeguards the device.
Super surveillance
AXIS Q6358-LE offers outstanding 4K UHD and features an extremely light-sensitive ½” inch sensor to deliver clear, bright images and better handling of shadows. Lightfinder and Forensic WDR provide details even in challenging light conditions. Plus, OptimizedIR allows for surveillance in total darkness up to 300 m without the need for extra lighting. With 31x optical zoom and quick zoom, you can easily follow fast-moving objects. Plus, laser focus ensures precise focus– every time. Axis Zipstream with support for AV1, H.264, and H.265 significantly lowers bandwidth and storage requirements without compromising image quality. Furthermore, this PTZ camera offers support for audio with a midspan and four I/O ports.

Secure inside and out
AXIS Q6358-LE includes Axis Edge Vault, a hardware-based cybersecurity platform that safeguards the device and protects sensitive information from unauthorized access. And it offers FIPS 140-3 Level 3 certified, secure cryptographic key storage and operations. This IP66-, IK10-, and NEMA 4x-rated device is impact- and weather-resistant. And its defog functionality ensures clear images despite fog or smog. Thanks to shock detection, you can be informed if there's any attempts to interfere with the camera. Furthermore, with support for fiber connection and PoE, it allows for cost-effective installation and long-distance connections.

ARTPEC-9 for unmatched performance
ARTPEC-9 refines the remarkable features and capabilities that characterized previous generations of our in-house-designed SoC: low bitrate, AI-powered analytics, superior imaging, and built-in cybersecurity. It also introduces AV1, an open-source video encoding standard from the Alliance for Open Media. With support for AV1 and enhanced image processing, ARTPEC-9 delivers high-quality video with uncompromised detail and clarity, and best-in-class bitrate. Together with Axis Zipstream, AV1 also ensures hassle-free video both on-prem and in the cloud. What’s more, ARTPEC-9 powers advanced analytics applications that detect objects earlier and analyze events more precisely.

AI-powered with advanced features
Featuring a deep learning processing unit (DLPU), this AI-based camera lets you run advanced features and powerful analytics on the edge. It comes with AXIS Object Analytics preinstalled to detect, classify, track, and count humans, vehicles, and types of vehicles. With AXIS Image Health Analytics preinstalled, you’ll be notified if your image is blocked, degraded, under-exposed, or redirected. It also offers autotracking 2 with click-and-track functionality for active object tracking. And an orientation aid enables dynamic text overlays with street names and a compass symbol for quick orientation. Additionally, where privacy must be kept, chameleon masking makes it possible to automatically change the color of the masking depending on the background color of the image.
Part number for ordering
Name | Axis region | Part number |
---|---|---|
AXIS Q6358-LE No Midspan | AR, AU, BR, CN, EU, JP, KR, UK, US | 02977-301 |
AXIS Q6358-LE | KR | 02977-007 |
AXIS Q6358-LE | AU | 02977-006 |
AXIS Q6358-LE | AR | 02977-008 |
AXIS Q6358-LE | UK | 02977-003 |
AXIS Q6358-LE | EU | 02977-002 |
AXIS Q6358-LE | JP | 02977-005 |
AXIS Q6358-LE | US | 02977-004 |
AXIS Q6358-LE | CN | 02977-009 |
Technical Specifications
Property Description | Property Value |
---|---|
Property description | Property value |
Lightfinder | Lightfinder 2.0 |
Min illumination/ light sensitivity (Color) | 0.11 lux |
Min illumination/ light sensitivity (B/W) | 0.001 lux |
Image sensor | CMOS |
Image sensor size | 1/1.8" |
Wide dynamic range | Forensic WDR |
Signed OS | Yes |
Secure boot | Yes |
TPM | – |
Built-in IR | Yes |
OptimizedIR | Yes |
Local storage (memory card slot) | Yes |
Operating temperature | -50 to 55 °C |
Outdoor Ready | Yes |
Vandal rating | IK10 |
IP rating | IP66,IP67 |
Designed for repaint | Yes |
Autotracking version | Autotracking 2 |
Orientation aid | orientation aid PTZ |
Max video resolution | 3840x2160 |
Max frames per second | 50/60 |
Day and Night functionality | Yes |
Electronic image stabilization | Yes |
Focal length | 6.91 - 214.64 mm |
Horizontal field of view | 58.5 - 2.3 ° |
Vertical field of view | 34.9 - 1.4 ° |
Optical zoom | 31 |
Pan range | 360 endless |
Tilt range | +20 to -90 |
Guard tour | preset position tour |
Digital zoom | 12 |
Zipstream | Yes |
H.264 | Baseline, High, Main |
H.265 | Yes |
AV1 | On |
Motion JPEG | Yes |
Audio Support * | Yes / - |
Built-in microphone | - |
Audio detection | – |
Active tampering | Yes |
Alarm inputs/outputs | – |
PoE Class | 6 |
