AXIS F1025 Sensor Unit 0735-001 0735-009 0734-001 0734-009

Pinhole lens and HDTV resolution for extremely discreet indoor surveillance Flexible, extremely discreet design for indoor use Pinhole lens with 1080p resolution Wide 92° horizontal field of view Supports WDR – Forensic Capture (with AXIS F41/F44 Main Unit) AXIS F1025 Sensor Unit, together with an AXIS F Main Unit, is ideal for use in extremely discreet indoor surveillance applications, such as in ATMs (automated teller machines), banks, stores, hotels and elevators. The small AXIS F1025 unit can be installed, for instance, in tight places, in doorways, behind metal sheets or flush-mounted in a wall or ceiling, with only a pin hole visible for the lens. Extremely discreet installation AXIS F1025 comprises an image sensor with 1080p resolution (1920 x 1080 pixels) and a pinhole lens that provides a wide 92° horizontal field of view. AXIS F1025 comes with a 3-m or 12-m (10 ft. or 39 ft.) pre-mounted cable for connection to an AXIS F Main Unit. An AXIS F8202 Straight Mounting Bracket is included for mounting on a flat surface. WDR – Forensic Capture AXIS F1025 also supports Wide Dynamic Range (WDR) – Forensic Capture, which can be activated when the sensor unit is connected to a main unit that supports this feature. WDR – Forensic Capture enables a high level of detail to be visible in both the bright and dark areas of a scene. At left, image without WDR – Forensic Capture, where only details in the bright areas are visible. At right, image from AXIS F1025 Sensor Unit and AXIS F41 Main Unit with WDR – Forensic Capture, where details in both bright and dark areas are visible. Image sensor CMOS Wide dynamic range Forensic Capture Min illumination/ light sensitivity (Color) 0.3 lux Max video resolution 1920x1200 Max frames per second 50/60 Focal length 3.7 mm Varifocal lens No Aperture 2.5 Horizontal field of view 92 ° Vertical field of view 45 ° Lens mount M12 Replaceable lens Yes Operating temperature -30 to 55 °C
