AXIS F1005-E Standard Sensor Unit Standard Lens 2MP Outdoor Ready 0675-001 0676-001 0676-009 0675-009

Brand: AXIS
Model: AXIS-F1005-E-SENSOR-UNIT
Weight: 116g
Dimensions: 30mm x 30mm x 2.80mm

Robust design enables highly discreet indoor, outdoor and mobile surveillance Flexible, rugged design for indoor, outdoor and mobile use Fixed lens with 1080p resolution Wide 113° horizontal field of view Supports WDR – Forensic Capture (with AXIS F41/F44 Main Unit) The AXIS F1005-E sensor unit, together with the AXIS F main unit, is ideal for use in highly discreet indoor, outdoor and mobile surveillance applications. AXIS F1005-E can be discreetly installed in tight places, can be flush mounted on a wall or ceiling, or can be incorporated into a light bar on top of an emergency vehicle. The rugged IP66 rated sensor unit withstands dust, rain, snow, vibration, shock and temperature fluctuations. Flexible installation AXIS F1005-E comprises an image sensor with a 1080p resolution (1920 x 1080 pixels) and a fixed lens that provides a wide 113° horizontal field of view. AXIS F1005-E also supports Wide Dynamic Range (WDR) – Forensic Capture, which can be activated when the sensor unit is connected to a main unit that supports this feature. WDR – Forensic Capture enables a high level of detail to be visible in both the bright and dark areas of a scene. AXIS F1005-E comes with a 3-m or 12-m (10 ft. or 39 ft.) pre-mounted cable for connection to an AXIS F Main Unit. An AXIS F8201 Vari-angle Mounting Bracket is included and enables the sensor unit to be secured and tilted in any position. The images above (backlight scenario at left, and nighttime scene at right) are taken with AXIS F1005-E Sensor Unit and AXIS F41 Main Unit with WDR – Forensic Capture The images above (backlight scenario at left, and nighttime scene at right) are taken with AXIS F1005-E Sensor Unit and AXIS F41 Main Unit with WDR – Forensic Capture AXIS F41 Main Unit and AXIS F1005-E Sensor Unit To the stratosphere with AXIS F44 and AXIS F1005-E Image sensor CMOS Wide dynamic range Forensic Capture Min illumination/ light sensitivity (Color) 0.3 lux Max video resolution 1920x1200 Max frames per second 50/60 Focal length 2.8 mm Varifocal lens No Aperture 2.0 Horizontal field of view 113 ° Vertical field of view 62 ° Lens mount M12 Replaceable lens Yes H.264 Baseline, High, Main Operating temperature -30 to 55 °C Outdoor Ready Yes IP rating IP66, IP67
