AXIS F1004 Sensor Unit 0765-001 0765-009

the sensor unit in walls or ceilings. Optional accessories Optional accessories include the surface mount AXIS F8214 Dome Accessory and the recessed mount AXIS F8224. The optional mounts enable AXIS F1004 to be tilted to achieve the desired viewing direction when installed in or on ceilings and walls. When AXIS F8214 or AXIS F8224 is used, AXIS F1004 would be the smallest fixed dome and recessed dome offerings from Axis, measuring 7.4 cm (2 7/8 in.) in diameter. Image sensor CMOS Wide dynamic range WDR Min illumination/ light sensitivity (Color) 0.4 lux Max video resolution 1280x720 Max frames per second 25/30 Focal length 2.1 mm Varifocal lens No Aperture 2.2 Horizontal field of view 102 ° Vertical field of view 56 ° Lens mount M12 Replaceable lens Yes Operating temperature -20 to 50 °C
