AXIS F1004 Pinhole Sensor Unit 01003-001 01003-009

and ticket/vending and health monitoring machines. Extremely discreet surveillance The sensor unit can be mounted in tight places, and behind a metal, plastic or glass panel that is up to 5.2 mm (3/16 in.) thick when used with the included mounting bracket. AXIS F1004 Pinhole offers a 57º horizontal field of view, a 720p video resolution, and good low-light performance in color. It comes with a detachable 8-m (26 ft) cable for connection to an AXIS F Main Unit. Image sensor CMOS Wide dynamic range WDR Min illumination/ light sensitivity (Color) 0.5 lux Max video resolution 1280x720 Max frames per second 25/30 Focal length 3.7 mm Varifocal lens No Aperture 2.5 Horizontal field of view 57 ° Vertical field of view 31 ° Lens mount M12 Replaceable lens Yes Operating temperature -20 to 50 °C
